Therm bend 45 degrees 150 x 150 mm
Thermal bending 45 degrees
Thermal bending 45 degrees
Therm bend with 20 mm grey Neopor® insulation shell.
Neopor® has a high insulation value, approximately 15% better than the previous therm bends with white Flamingo® shell.
The inner bend is made of high impact polystyrene (HIPS). It has a socket end and a spigot end. If you need a 90° bend, it is very easy to make it by connecting 2 45° bends together.
Used in conjunction with Duka therm pipes. Always remember to seal joints with glue or tape.
Dimensions 15×15 bend
A | B | C | D | E | F | G | H |
190 mm | 100 mm | 75 mm | 190 mm | 193 mm | 20 mm | 150 mm | 150 mm |
