DUKA S7
High-quality fan with 9 built-in functions. Easily change the function and find the setting that fits your life and your home. One of the functions is heat dissipation.
With DUKA S7 you get nine fans in one. The S7 is both a fan with eight optional ventilation solutions and an energy-saving heat transfer.
Installation, assembly and maintenance:
- Easy to install: Attach the frame constructed with integrated seals. Connect phase and neutral.
- Easy to select mode: Lift the cover. Select the mode.
- Easy to clean: Motor unit with bayonet catch and removable blade makes the fan easy to disassemble and clean.
- DUKA S7 fan
DUKA S7 has excellent performance, high pressure and low noise. Settings for optimal ventilation, self-adjusting humidity control, motion sensor, timer, ventilation function, thermostat, manual start/stop, self-calibrating motor with built-in control that optimises ventilation flow and counteracts cooling even when the fan is running at low speed.
S7 ventilation programmes:
With continuous basic ventilation:
Function 1: Fully automatic, three speeds:
Constant basic ventilation - low speed 40 m3/h
Motion and light sensor - medium
Speed 60 m3/h
Humidity control - high speed 95 m3/h
Function 2: Fully automatic, three speeds with max speed:
Constant basic ventilation - low speed 40 m3/h
Motion and light sensor - medium
Speed 60 m3/h
Humidity control - max. speed 110 m3/h
Function 3: Automatic, two speeds without motion and light sensor
Constant basic ventilation - low speed 40 m3/h
Humidity control - high speed 95 m3/h
Function 8: Automatic, two speeds without motion and light sensor - with increased basic ventilation
Constant basic ventilation - medium speed 60 m3/h
Humidity control - high speed 95 m3/h
Heat flow
Function 7 Heat flow, with thermostat
The fan starts at 28°C and transfers the blast heat to an adjacent room. It runs at a high speed of 95m3/h. The fan stops again at 24°C
Function 0 Not used.
Function 4: Auto start when there is movement in the room, when the light is switched on or when the humidity level rises sharply.
Sensor - medium speed 60 m3/h
Note the 2½ minute delay in this function.
Humidity control - high speed 95 m3/h
Function 5: Manual start/stop on switch.
The fan can be connected to manual start via a separate light/power switch. When the switch is switched on
switch, the fan starts and runs at a high speed of 95 m3/h. When the switch is turned off, the fan stops.
Function 6: Auto start when there is movement in the room, when the light is switched on or when the humidity level rises sharply.
Sensor - medium speed 60 m3/h
Humidity control - high speed 95 m3/h
Extra in function 6: Venting function.
If the fan has not been active for at least 24 hours, it starts automatically and runs between
speed (60 m3/h) for 30 minutes every 12 hours.
Function 9: Moisture management
Auto start when the moisture level rises sharply.
Humidity control - high speed 95 m3/h
