Pro 32 TH

Fan with silent motor, high performance and low heat consumption with humidity and time control.


SKU 333423 Categories , .

DB number 1702490VVS number 353800122EAN 5708605012132


Pro 32TH



Pro 32TH is a larger version of the well-known Pro 30 fan. Pro 32TH also has a silent motor, designed for larger bathrooms and other rooms in need of increased ventilation. Pro 32TH has a capacity up to 183 m3/h. Despite its high performance, power consumption is very low. The fan is equipped with ball bearings, which ensures a long service life, and the fan has a 5-year warranty.

The fan can be either ceiling-mounted or wall-mounted.
For ceiling installation, the supplied clear foil damper must be removed from the fan's outlet spigot. This is important to prevent condensation from collecting on the back of the damper, which can then run into the fan motor and short-circuit it.
Leaving the damper off also provides better ventilation when the fan is not running, due to the natural buoyancy.

Humidity and time control
The humidity level can be set as needed (between 60-90% RH), whereby the fan starts when the humidity in the room exceeds this limit and runs until the humidity is below the limit again.

The timer can be set between 2-30 minutes. The timer is activated when the switch is turned on and then runs for the set number of minutes after it is switched off.

Capacity free blowing
Power connection
Enclosure material
Bearing type
Approval
Channel connection
185 m3/h
230 V / 50 Hz
ABS plastic (White)
Ball bearings
IP 45
Ø125 mm

Device
Item no.
DB no.
Plumbing no.
Pro 32 TH
333423
1702490
353800122


Consumption

guaranteed

sound level
