Duct fan 160 TT Silent
Sound and heat insulated duct fan with 2 speeds in lacquered metal casing.
160 TT Silent
DUKA Ventilation's TT silent duct fans are extra soundproofed for silent operation. The duct fans can be used with Ø160 mm ventilation pipes. Can be used for combined supply and exhaust ventilation in commercial and industrial spaces with strict noise requirements such as libraries, conference rooms, classrooms, kindergartens, playrooms etc.
The duct fan housing is made of steel with a polymer coating. The casing is sound and heat insulated with 50 mm mineral wool.
The duct fan is also suitable for extraction in wet rooms, living rooms and storage rooms.
The duct fans are equipped with low power consumption double-speed motors. The motors are equipped with overheating protection. The unit's ball bearings ensure a long service life. An external controller can be connected to enable stepless regulation of the duct fan.
The enclosure has mounting brackets for easy wall, ceiling or floor installation.
Specifications
Data | Specification |
Capacity free blowing | 555 m3/h |
Engine speed | 2645 rpm |
Power connection | 1 ~ 230 V / 50/60 Hz |
Enclosure material | Steel with 50 mm insulation |
Approval | IPX4 |
Channel connection | Ø160 mm |
Can be used with:
